87234 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN HEADER R/A 10POS 3.18MM
| Part | Contact Finish Thickness - Post | Contact Length - Post [custom] | Contact Length - Post | Mounting Type | Contact Length - Mating | Contact Length - Mating | Number of Positions | Style | Fastening Type | Contact Finish - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Material | Termination | Insulation Color | Contact Finish - Mating | Insulation Height [z] | Insulation Height [z] | Shrouding | Number of Positions Loaded | Current Rating (Amps) | Contact Shape | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Contact Material | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Flash | 0.11 in | 2.79 mm | Right Angle Through Hole | 8.08 mm | 0.318 in | 10 | Board to Board Cable | Push-Pull | Gold | 0.76 Ám | 30 Áin | Glass Filled Nylon Polyamide (PA) | Solder | Black | Gold | 3.5 mm | 0.138 " | Unshrouded | All | 3 A | Square | Male Pin | 105 ░C | -65 ░C | 1 | Phosphor Bronze | Header |
