EM6819F4 Series
Manufacturer: EM Microelectronic
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
SUB-1V (0.6V) 8BIT FLASH MCU DC-
| Part | Voltage - Input (Maximum) | Voltage - Input (Minimum) | Applications | Mounting Type | Number of Outputs | Operating Temperature (Min) | Operating Temperature (Max) | Package Length | Package Name | Package Width | Voltage - Output | Speed | Core Processor | Core Size (Bit Width) | Peripherals | Oscillator Type | Number of I/O | Connectivity | A/D Channels | A/D Resolution (bits) | RAM Size Width | RAM Size Depth | Program Memory Type | Program Memory Size | Program Memory Depth | Program Memory Width | Voltage - Supply (Vcc/Vdd) Maximum | Voltage - Supply (Vcc/Vdd) Minimum | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EM Microelectronic | 3.6 V | 0.9 V | Converter Power Supplies | Surface Mount | 8 | -40 °C | 85 °C | 0.173 in | 16-TSSOP | 4.4 mm | Multiple | ||||||||||||||||||
EM Microelectronic | Surface Mount | -40 °C | 85 °C | 0.173 in | 16-TSSOP | 4.4 mm | 15 MHz | CR816L | 8 Bit | Brown-out Detect POR PWM Reset Voltage Detect WDT | External Internal | 12 | I2C SPI UART USART | 4 count | 10 bit | 8 bit | 256 | FLASH | 11.5 KB | 4 K | 23 | 3.6 V | 0.9 V | ||||||
 EM Microelectronic | Surface Mount | -40 °C | 85 °C | 4 mm | 20-QFN | 4 mm | 15 MHz | CR816L | 8 Bit | Brown-out Detect POR PWM Reset Temp Sensor Voltage Detect WDT | External Internal | 24 | I2C SPI UART USART | 8 count | 10 bit | 8 bit | 512 | FLASH | 11.5 KB | 4 K | 23 | 3.6 V | 0.9 V | 20-VFQFN Exposed Pad |
