T351 Series

Manufacturer: KEMET

Catalog

TANTALUM CAPACITORS - SOLID LEADED 10VOLTS 4.7UF 10%

Part	Mounting Type	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [diameter]	Type	Package / Case	Tolerance	Manufacturer Size Code	Features	Voltage - Rated	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET T351A475K010AT7301	Through Hole	4.7 µF	9.6 mm	0.378 "	8 Ohm	4.5 mm	0.177 "	Conformal Coated	Disc Radial	10 %	T351A	General Purpose	10 V	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351A225K016AT	Through Hole	2.2 µF	9.6 mm	0.378 "	8 Ohm	4.45 mm	0.175 in	Conformal Coated	Radial	10 %	A	General Purpose	16 V	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351E685K025AT	Through Hole	6.8 µF	11.2 mm	0.441 in	3.1 Ohm	5.5 mm	0.217 in	Conformal Coated	Disc Radial	10 %	T351E	General Purpose	25 VDC	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351A105K035AT	Through Hole	1 µF	9.6 mm	0.378 "	8 Ohm	4.45 mm	0.175 in	Conformal Coated	Radial	10 %	A	General Purpose	35 V	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351F336M010AT	Through Hole	33 ÁF			2.1 Ohm	6 mm	0.236 in	Conformal Coated	Disc Radial	20 %	T351F	General Purpose	10 V	2.54 mm	0.1 in	-55 C	125 °C	12.2 mm	0.48 in
KEMET T351B155M035AT7301	Through Hole	1500 nF			6 Ohm	4.5 mm	0.177 "	Conformal Coated	Disc Radial	20 %		General Purpose	35 V	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351H226K025AS	Through Hole	22 µF			1.5 Ohm	7.6 mm	0.299 in	Conformal Coated	Disc Radial	10 %	T351H	General Purpose	25 VDC	2.54 mm	0.1 in	-55 C	125 °C		0.5 in	12.7 mm
KEMET T351C685K016AS7301	Through Hole	6.8 µF			4 Ohm	5 mm	0.197 in	Conformal Coated	Disc Radial	10 %	T351C	General Purpose	16 V	2.54 mm	0.1 in	-55 C	125 °C		0.421 "	10.7 mm
KEMET T351E106K025AS7301	Through Hole	10 µF	11.2 mm	0.441 in	2.5 Ohm	5.5 mm	0.217 in	Conformal Coated	Disc Radial	10 %	T351E	General Purpose	25 VDC	2.54 mm	0.1 in	-55 C	125 °C
KEMET T351E106M016AS7301	Through Hole	10 µF	11.2 mm	0.441 in	3.2 Ohm	5.5 mm	0.217 in	Conformal Coated	Disc Radial	20 %	T351E	General Purpose	16 V	2.54 mm	0.1 in	-55 C	125 °C
