6609952 Series
Manufacturer: TE Connectivity Corcom Filters
Beta
⌘K
PWR ENT MOD RCPT IEC320-C14 PNL
| Part | Voltage Rating - Appliance Inlet | Panel Thickness [Min] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Max] | Panel Cutout Dimensions | Mounting Type | Filter Type | Accomodates a Fuse | Fuse Holder, Drawer | Connector Type | Connector Style | Approval Agency | Current Rating - Appliance Inlet | Current Rating - Filter | Termination | Termination | Termination | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 3 A | 3 A | Quick Connect | 0.187 " | 4.7 mm | Shielded | |
 TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 10 A | 10 A | Quick Connect | 0.187 " | 4.7 mm | Voltage Selector | |
 TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial Medical | Fuse Holder | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 10 A | 10 A | Quick Connect | 0.187 " | 4.7 mm | Conversion Clip Shielded | |
TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial Medical | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 6 A | 6 A | Quick Connect | 0.187 " | 4.7 mm | |||
TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Fuse Holder | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 3 A | 3 A | Quick Connect | 0.187 " | 4.7 mm | Conversion Clip Voltage Selector | ||
TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Fuse Holder | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 3 A | 3 A | Quick Connect | 0.187 " | 4.7 mm | Conversion Clip Voltage Selector | ||
 TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 10 A | 10 A | Quick Connect | 0.187 " | 4.7 mm | ||
TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial Medical | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 3 A | 3 A | Quick Connect | 0.187 " | 4.7 mm | |||
TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 10 A | 10 A | Quick Connect | 0.187 " | 4.7 mm | Shielded Voltage Selector | |
 TE Connectivity Corcom Filters | 120 VAC | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Variable Size | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial Medical | Twin Fused | Receptacle Male Blades - Module | IEC 320-C14 | CSA UL VDE | 6 A | 6 A | Quick Connect | 0.187 " | 4.7 mm |
