846-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 50POS 0.125
| Part | Material - Insulation | Termination Rows | Number of Positions | Contact Finish | Read Out | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Pitch | Pitch | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Contact Material | Termination | Number of Rows | Gender | Color | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 50 | Gold | Single | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Right Angle Through Hole | 3.18 mm | 0.125 in | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder | 1 | Female | Green | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 50 | Gold | Dual | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder | Female | Green | 2 | 3.25 mm | 0.128 " | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 50 | Gold | Single | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Wire Wrap | 1 | Female | Green | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 50 | Gold | Dual | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder | Female | Green | 2 | 3.96 mm | 0.156 " | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 50 | Gold | Single | Floating Bobbin Top Mount Opening | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Wire Wrap | 1 | Female | Green | 2.95 mm | 0.116 " | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 50 | Gold | Single | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder Eyelet(s) | 1 | Female | Green | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 50 | Gold | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder | Female | Green | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 50 | Gold | Single | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder | 1 | Female | Green | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 50 | Gold | Dual | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 3.18 mm | 0.125 in | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Solder Eyelet(s) | Female | Green | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 50 | Gold | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Through Hole | 3.18 mm | 0.125 in | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Cantilever | Copper Alloy | Wire Wrap | Female | Green | 2 | 2 |
