1.5KE11 Series
1500W Transient Voltage Suppressor
Manufacturer: Vishay General Semiconductor - Diodes Division
Catalog
1500W Transient Voltage Suppressor
Beta
⌘K
1500W Transient Voltage Suppressor
1500W Transient Voltage Suppressor
1500W Transient Voltage Suppressor
| Part | Unidirectional Channels | Operating Temperature (Min) | Operating Temperature (Max) | Qualification | Voltage - Reverse Standoff (Typ) | Package Name | Current - Peak Pulse | Grade | Power Line Protection | Type | Power - Peak Pulse | Voltage - Breakdown (Min) | Voltage - Clamping (Max) | Package / Case | Mounting Type | Applications | Bidirectional Channels |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay General Semiconductor - Diodes Division | 1 | -55 °C | 175 °C | AEC-Q101 | 8.92 V | 1.5KE | 92.6 A | Automotive | No | Zener | 1500 W | 9.9 V | 16.2 V | Axial DO-201AA DO-27 | Through Hole | ||
Vishay General Semiconductor - Diodes Division | 1 | -55 °C | 175 °C | 9.4 V | 1.5KE | 96.2 A | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | General Purpose | |||
Vishay General Semiconductor - Diodes Division | -55 °C | 175 °C | AEC-Q101 | 9.4 V | 1.5KE | 100 A | Automotive | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | Telecom | 1 | |
Vishay General Semiconductor - Diodes Division | -55 °C | 175 °C | 9.4 V | 1.5KE | 96.2 A | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | General Purpose | 1 | |||
Vishay General Semiconductor - Diodes Division | 1 | -55 °C | 175 °C | 8.92 V | 1.5KE | 92.6 A | No | Zener | 1500 W | 9.9 V | 16.2 V | Axial DO-201AA DO-27 | Through Hole | General Purpose | |||
Vishay General Semiconductor - Diodes Division | 1 | -55 °C | 175 °C | AEC-Q101 | 9.4 V | 1.5KE | 100 A | Automotive | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | Telecom | |
Vishay General Semiconductor - Diodes Division | -55 °C | 175 °C | AEC-Q101 | 9.4 V | 1.5KE | 96.2 A | Automotive | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | 1 | ||
 Vishay General Semiconductor - Diodes Division | -55 °C | 175 °C | 9.4 V | 1.5KE | 96.2 A | No | Zener | 1500 W | 10.5 V | 15.6 V | Axial DO-201AA DO-27 | Through Hole | General Purpose | 1 | |||
Vishay General Semiconductor - Diodes Division | 1 | -55 °C | 175 °C | AEC-Q101 | 8.92 V | 1.5KE | 92.6 A | Automotive | No | Zener | 1500 W | 9.9 V | 16.2 V | Axial DO-201AA DO-27 | Through Hole |
