307-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 26POS 0.156
| Part | Termination Rows | Material - Insulation | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Gender | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Mounting Type | Card Type | Number of Positions/Bay/Row | Termination | Card Thickness [Max] | Card Thickness [Min] | Color | Pitch | Pitch | Read Out | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Rows [custom] | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | Female | 26 | -40 C | 105 ░C | Semi Bellows | Surface Mount | Non Specified - Dual Edge | 13 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Dual | 0.25 Ám | 10 Áin | Gold | 2 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Female | 13 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Single Edge | 13 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Single | Tin | 1 | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | Female | 26 | -40 C | 105 ░C | Semi Bellows | Right Angle Through Hole | Non Specified - Dual Edge | 13 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Dual | Tin | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Female | 13 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Single Edge | 13 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | Gold | 1 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Female | 26 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Dual Edge | 13 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Dual | 0.25 Ám | 10 Áin | Gold | 2 | Card Guides | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Female | 13 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Single Edge | 13 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | Gold | 1 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Female | 26 | -40 C | 105 ░C | Semi Bellows | Surface Mount | Non Specified - Dual Edge | 13 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Dual | 0.25 Ám | 10 Áin | Gold | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Female | 26 | -40 C | 105 ░C | Semi Bellows | Right Angle Through Hole | Non Specified - Dual Edge | 13 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Dual | Tin | 2 | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | Female | 13 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Single Edge | 13 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | Gold | 1 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | Female | 13 | -40 C | 105 ░C | Semi Bellows | Through Hole | Non Specified - Single Edge | 13 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | Gold | 1 |
