396-054 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Card Type | Gender | Flange Feature | Number of Positions | Contact Material | Contact Finish | Termination | Pitch | Pitch | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Read Out | Color | Operating Temperature [Min] | Operating Temperature [Max] | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | 4-40 Threaded Insert Top Mount Opening | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | 4-40 Threaded Insert Top Mount Opening | 54 | Copper Alloy | Gold | Wire Wrap | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Side Mount Opening Unthreaded | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | Card Extender | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Flush Mount Top Opening Unthreaded | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Floating Bobbin Flush Mount | 54 | Copper Alloy | Gold | Solder Eyelet(s) | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | Card Extender | 0.116 " | 2.95 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Flush Mount Top Opening Unthreaded | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | Card Extender | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | 4-40 Flush Mount Threaded Insert Top Opening | 54 | Copper Alloy | Gold | Wire Wrap | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Floating Bobbin Top Mount Opening | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | M3 Threaded Insert Top Mount Opening | 54 | Copper Alloy | Gold | Wire Wrap | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | Female | Flush Mount Top Opening Unthreaded | 54 | Copper Alloy | Gold | Solder | 3.18 mm | 0.125 in | 2 | 0.25 Ám | 10 Áin | Through Hole | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 27 | Dual | Black | -40 C | 105 ░C | 0.156 " | 3.96 mm |
