AWHW-200-26 Series
Manufacturer: Assmann WSW Components
Beta
⌘K
DIN 41651 HEADER MALE THR 26PIN
| Part | Number of Positions Loaded | Contact Type | Insulation Height | Insulation Height | Shrouding | Fastening Type | Connector Type | Style | Mounting Type | Contact Shape | Contact Material | Number of Positions | Material Flammability Rating | Insulation Color | Contact Finish Thickness - Mating | Contact Length - Mating | Contact Length - Mating | Number of Rows [custom] | Contact Length - Post | Contact Length - Post | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Termination | Features | Row Spacing - Mating | Row Spacing - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Insulation Height [custom] | Insulation Height [custom] | Contact Length - Post [x] | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Assmann WSW Components | All | Male Pin | 8 mm | 0.315 in | Shrouded - 4 Wall | Latch Lock/Eject Hooks | Header | Board to Cable/Wire | Right Angle Through Hole | Square | Brass | 26 | UL94 V-0 | Black | Flash | 0.142 in | 3.6 mm | 2 | 0.118 in | 3 mm | Gold | 0.079 " | 2 mm | Solder | Keying Slot | 2 mm | 0.079 in | -40 C | 105 ░C | Glass Filled Nylon 9T Polyamide (PA9T) | ||||
 Assmann WSW Components | All | Male Pin | Shrouded - 4 Wall | Latch Lock/Eject Hooks | Header | Board to Cable/Wire | Through Hole | Square | Brass | 26 | UL94 V-0 | Black | Flash | 0.142 in | 3.6 mm | 2 | Gold | 0.079 " | 2 mm | Solder | Keying Slot | 2 mm | 0.079 in | -40 C | 105 ░C | Glass Filled Nylon 9T Polyamide (PA9T) | 16.2 mm | 0.638 in | 0.126 " | 3.2 mm |
