857-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 24POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Termination | Contact Type | Number of Positions | Card Type | Read Out | Contact Finish | Number of Rows [custom] | Flange Feature | Contact Material | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Mounting Type | Gender | Color | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Wire Wrap | Semi Bellows | 24 | Non Specified - Dual Edge | Dual | Tin | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 12 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Semi Bellows | 48 | Non Specified - Dual Edge | Dual | Tin | 2 | Side Mount Opening Unthreaded | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 48 | Non Specified - Dual Edge | Dual | Gold | 2 | Floating Bobbin Flush Mount | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Right Angle Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 48 | Non Specified - Dual Edge | Dual | Gold | 2 | Floating Bobbin Flush Mount | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Right Angle Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 24 | Non Specified - Single Edge | Single | Gold | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.25 Ám | 10 Áin | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 24 | Non Specified - Single Edge | Single | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.25 Ám | 10 Áin | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Semi Bellows | 24 | Non Specified - Single Edge | Single | Tin | Flush Mount Top Opening Unthreaded | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 24 | Non Specified - Single Edge | Single | Gold | Flush Mount Top Opening Unthreaded | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 1 | 0.25 Ám | 10 Áin | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Semi Bellows | 24 | Non Specified - Single Edge | Single | Gold | Copper Alloy | 24 | 125 °C | -40 C | 3.96 mm | 0.156 in | Through Hole | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.25 Ám | 10 Áin | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Solder | Semi Bellows | 24 | Non Specified - Dual Edge | Dual | Gold | 2 | Flush Mount Top Opening Unthreaded | Copper Alloy | 12 | 125 °C | -40 C | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Card Extender |
