6EP13321 Series

Manufacturer: Siemens

Catalog

AC/DC CONVERTER 24V 60W

Part	Minimum Load Required	Standard Number	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Applications	Type	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Output 1	Approval Agency	Number of Outputs	Features	Current - Output 1	Efficiency	Input Type	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Current - Output (Max) [Max]	DC Voltage - Input (Min) [Min]	DC Voltage - Input (Max) [Max]
Siemens 6EP13321SH71		60950-1; UL 508	Chassis Mount	0 °C	60 °C	60 W	100 mm	3.94 in	70 mm	75 mm	2.76 "	2.95 "	Hazardous Locations Industrial ITE (Commercial)	Enclosed	85 VAC 132 VAC	176 VAC 264 VAC	24 V	CB CE CSA cUL cULus cURus UL	1	Adjustable Output IP20 Universal Input	2.5 A	83 %
Siemens 6EP13321SH43		60950-1; UL 508		-20 ░C	70 °C		90 mm	3.54 "	72 mm	52.5 mm	2.83 "	2.07 in	Industrial ITE (Commercial)				24 V	CB cCSAus CE cULus cURus	1	Adjustable Output IP20		88 %	AC or DC	264 VAC	85 VAC	2.5 A	110 V	300 V
