630M SERIES RIGHT ANGLE D-SUB
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Color | Dielectric Material | Contact Material | Number of Rows [custom] | Contact Finish Thickness | Mounting Type | Number of Positions | Current Rating (Amps) | Termination | Contact Finish | Connector Style | Shell Size, Connector Layout | Shell Size, Connector Layout | Features | Connector Type | Contact Type | Flange Feature | Flange Feature | Material Flammability Rating | Shell Material, Finish | Backset Spacing | Backset Spacing | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Flash | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Board Lock Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | Nickel Plated Steel | 9.4 mm | 0.37 in | ||
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | Nickel Plated Steel | 9.4 mm | 0.37 in | 0.38 µm | 15 µin | |
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Flash | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | |||
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Shielded | Receptacle Female Sockets | Signal | Housing/Shell (Unthreaded) | UL94 V-0 | Nickel Plated Steel | 9.4 mm | 0.37 in | 0.76 Ám | 30 Áin | ||
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | Nickel Plated Steel | 9.4 mm | 0.37 in | 0.38 µm | 15 µin | |
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Flash | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Board Lock Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | |||
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Shielded | Receptacle Female Sockets | Signal | Housing/Shell (Unthreaded) | UL94 V-0 | 9.4 mm | 0.37 in | 0.38 µm | 15 µin | |||
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Flash | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Board Lock Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | Nickel Plated Steel | 9.4 mm | 0.37 in | ||
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Mounting Brackets Shielded | Receptacle Female Sockets | Signal | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | 2 | Right Angle Through Hole | 37 | 5 A | Solder | Gold | D-Sub | 4 | DC C | Mounting Brackets Shielded | Receptacle Female Sockets | Signal | Housing/Shell | 4-40 | UL94 V-0 | 9.4 mm | 0.37 in | 0.38 µm | 15 µin |
