357-048 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 48POS 0.156
...
| Part | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Finish | Color | Contact Type | Contact Material | Termination | Flange Feature | Termination Rows | Card Type | Read Out | Number of Rows | Number of Positions/Bay/Row [custom] | Pitch [x] | Pitch [x] | Mounting Type | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Features | Gender | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | Semi Bellows | Copper Alloy | Solder Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole Right Angle | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | 10 Áin | 0.25 Ám | Card Guides | Female | ||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Tin | Black | Semi Bellows | Copper Alloy | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole Right Angle | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | Card Guides | Female | ||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | Semi Bellows | Copper Alloy | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Board Edge Straddle Mount | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | 10 Áin | 0.25 Ám | Female | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Tin | Black | Semi Bellows | Copper Alloy | Solder | Flush Mount Top Opening Unthreaded | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Board Edge Straddle Mount | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | Female | 3.96 mm | 0.156 in | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | Semi Bellows | Copper Alloy | Solder | Flush Mount Top Opening Unthreaded | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | 10 Áin | 0.25 Ám | Female | 3.96 mm | 0.156 in | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Tin | Black | Semi Bellows | Copper Alloy | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | Female | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | Semi Bellows | Copper Alloy | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Board Edge Straddle Mount | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | 10 Áin | 0.25 Ám | Female | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Tin | Black | Semi Bellows | Copper Alloy | Solder | Floating Bobbin Flush Mount | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Board Edge Straddle Mount | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | Female | 2.95 mm | 0.116 in | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Tin | Black | Semi Bellows | Copper Alloy | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | Card Guides | Female | ||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | Semi Bellows | Copper Alloy | Solder Eyelet(s) | Flush Mount Side Opening Unthreaded | 2 | Non Specified - Dual Edge | Dual | 2 | 24 | 0.156 in | 3.96 mm | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | 48 | 10 Áin | 0.25 Ám | Female | 3.25 mm | 0.128 " |
