A8GS-P111 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SWITCH ROCKER SPST 16A 125V
| Part | Mechanical Life | Electrical Life | Actuator Marking | Operating Temperature [Max] | Operating Temperature [Min] | Color - Actuator/Cap | Actuator Type | Approval Agency | Mounting Type | Circuit | Termination Style | Voltage Rating - AC | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Current Rating (Amps) | Switch Function | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 30000 Steps | 10000 Cycles | No Marking | 55 °C | -10 °C | Black | Concave (Curved) | cULus EN UL | Panel Mount Snap-In | SPST | Solder Lug | 125 V | 27.7 mm | 15.2 mm | 16 A | On-Off | |
 Omron Electronics Inc-EMC Div | 30000 Steps | 10000 Cycles | No Marking | 55 °C | -10 °C | Black | Concave (Curved) | cULus EN UL | Panel Mount Snap-In | SPST | Solder Lug | 125 V | 27.7 mm | 15.2 mm | 16 A | On-Off | Remote Reset Function |
