ADS6245 Series
Manufacturer: Texas Instruments
Beta
⌘K
ADS6245EVM
| Part | Contents | Utilized IC / Part | Sampling Rate (Per Second) | Supplied Contents | Data Interface | Number of Bits | Input Range | Number of A/D Converters | Power (Typ) @ Conditions | Ratio - S/H:ADC | Architecture | Configuration | Features | Reference Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Input Type | Supplier Device Package | Package / Case | Mounting Type | Voltage - Supply, Analog [Max] | Voltage - Supply, Analog [Min] | Number of Inputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Board(s) | ADS6245 | 125 M | Board(s) | Parallel Serial | 14 | 2 Vpp | 2 | 500 mW | ||||||||||||||||
 Texas Instruments | 125 M | LVDS - Serial | 14 | 2 | 1:1 | Pipelined | S/H-ADC | Simultaneous Sampling | External Internal | 85 °C | -40 °C | 3.6 V | 3 V | Differential | 48-VQFN (7x7) | 48-VFQFN Exposed Pad | Surface Mount | 3.6 V | 3 V | 2 | |||||
Texas Instruments | 125 M | LVDS - Serial | 14 | 2 | 1:1 | Pipelined | S/H-ADC | Simultaneous Sampling | External Internal | 85 °C | -40 °C | 3.6 V | 3 V | Differential | 48-VQFN (7x7) | 48-VFQFN Exposed Pad | Surface Mount | 3.6 V | 3 V | 2 |
