189-009 Series
Manufacturer: NorComp Inc.
Beta
⌘K
STACKED D SUB CONNECTOR, DUAL PORT, UPPER - RECEPTACLE / LOWER - RECEPTACLE, DE, 9 CONTACTS
| Part | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Form | Color | Material Flammability Rating | Contact Finish | Connector Type | Termination | Mounting Type | Flange Feature | Number of Rows [custom] | Number of Positions | Shell Size, Connector Layout | Connector Style | Contact Finish Thickness | Shell Material, Finish | Contact Type | Backset Spacing | Backset Spacing | Current Rating (Amps) | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Shielded | |
 NorComp Inc. | -55 C | 105 ░C | Polyester Glass Filled | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents | ||||
 NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Grounding Indents Shielded | |
NorComp Inc. | Brass | -55 C | 105 ░C | Polyester Glass Filled | Black | UL94 V-0 | Gold | Plug Male Pins | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents | |||
NorComp Inc. | -55 C | 105 ░C | Polyester Glass Filled | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents | ||||
 NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | Housing/Shell | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Shielded | 4-40 |
 NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents Shielded | |
NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Plug Male Pins | Solder | Panel Mount Right Angle Through Hole | Housing/Shell | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Grounding Indents Shielded | 4-40 |
NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents Shielded | |
 NorComp Inc. | Brass | -55 C | 105 ░C | Nylon 9T Polyamide (PA9T) | Stamped | Black | UL94 V-0 | Gold | Plug Male Pins Receptacle Female Sockets | Solder | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | 2 | 9 | 1 | D-Sub - Stacked | Flash | Nickel Plated Steel | Signal | 8.08 mm | 0.318 " | 5 A | Board Lock Grounding Indents Shielded |
