6PCV Series
Manufacturer: TE Connectivity AMP Connectors
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
CONN BARRIER STRIP 16 POS 9.53MM SOLDER ST THRU-HOLE 25A/CONTACT PACKAGE
| Part | Voltage Rating | Bottom Termination | Number of Rows | Barrier Type | Current Rating | Number of Circuits | Pitch | Top Termination | Color | Terminal Block Type | Wire Gauge (AWG) (Min) | Wire Gauge (AWG) (Max) | Number of Wire Entries | Material - Insulation | Mounting Type | Terminal Screw Material | Operating Temperature | Terminal Screw Finish | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 300 VAC/DC | PC Pin | 1 | 3 Wall (Tri) | 25 A | 16 | 0.375 in | Screws | Black | Barrier Block | 12 AWG | 22 AWG | 16 | Thermoplastic | Through Hole | Steel | 105 °C | Clear Chromate Zinc | UL94 V-0 |
