11_TNC-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_TNC-50-7-10/133_NE
| Part | Center Contact Plating | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Mating Cycles | Voltage Rating | Dielectric Material | Body Finish | Connector Style | Number of Ports | Frequency - Max [Max] | Center Contact Material | Fastening Type | Shield Termination | Housing Color | Cable Group | Mounting Type | Connector Type | Impedance | Contact Termination | Contact Material | Contact Finish | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Crimp | Silver | RG-214 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Clamp | Silver | 223 400 RG-142 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Solder | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Crimp | Silver | 223 RG-142 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | |||
 Huber+Suhner, Inc. | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Silver | TNC | 11 GHz | Cap Free Hanging | Plug Male Pin | 50 Ohms | Brass | Gold | |||||||||||||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass Bronze | Threaded | Crimp | Silver | RG-178 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | 196 | ||
Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Silver | TNC | 1 | 11 GHz | Brass | Threaded | Solder | Silver | RG-405 (.086 Semi Rigid) | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Solder | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Crimp | Silver | RG-213 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Crimp | Silver | RG-58 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 165 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 11 GHz | Brass | Threaded | Crimp | Silver | RG-58 | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp | |||
 Huber+Suhner, Inc. | Gold | -65 ░C | 125 °C | Brass | 500 | 500 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | TNC | 1 | 15 GHz | Beryllium Copper | Threaded | Crimp | Silver | Free Hanging (In-Line) | Plug Male Pin | 50 Ohms | Crimp |
