M2027TN Series

Catalog

SWITCH ROCKER SP3T 6A 125V

Part	Mechanical Life	Electrical Life	Features	Operating Temperature [Max]	Operating Temperature [Min]	Switch Function	Actuator Marking	Termination Style	Approval Agency	Actuator Type	Color - Actuator/Cap	Current Rating (Amps)	Voltage Rating - AC	Voltage Rating - DC	Circuit	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Mounting Type
NKK Switches M2027TNW01-GB	50000 Cycles	25000 Steps	Jumper needed to achieve triple throw	85 °C	-30 ░C	On-On-Mom	No Marking	Solder Lug	CSA UL	Paddle	White	3 A 6 A	125 V	30 V	SP3T	12.4 mm	0.5 in	Flange Panel Mount
NKK Switches M2027TNW01-GA	50000 Cycles	25000 Steps	Jumper needed to achieve triple throw	85 °C	-30 ░C	On-On-Mom	No Marking	Solder Lug	CSA UL	Paddle	Black	3 A 6 A	125 V	30 V	SP3T	12.4 mm	0.5 in	Flange Panel Mount
NKK Switches M2027TNW01-DA	50000 Cycles	25000 Steps	Jumper needed to achieve triple throw	85 °C	-30 ░C	On-On-Mom	No Marking	Solder Lug	CSA UL	Concave	Black	3 A 6 A	125 V	30 V	SP3T	10.1 mm	17.8 mm	Flange Panel Mount
NKK Switches M2027TNW01-EC	50000 Cycles	25000 Steps	Jumper needed to achieve triple throw	85 °C	-30 ░C	On-On-Mom	No Marking	Solder Lug	CSA UL	Paddle	Red	3 A 6 A	125 V	30 V	SP3T	10.1 mm	17.8 mm	Flange Panel Mount
