DEUTSCH DTS Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
DTS 20 K 15-97 SA
| Part | Mounting Type | Connector Type | Shell Finish | Contact Material | Qualification | Shell Material | Color | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shielding | Fastening Type | Insert Material | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish - Mating | Primary Material | Ingress Protection | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Voltage Rating | Voltage Rating | Number of Positions | Orientation | Mounting Feature | Applications | Features | Shell Size - Insert |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Panel Mount | Receptacle Female Sockets | Passivated | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 260 °C | -65 ░C | Gold | Metal | Environment Resistant | 15 | 97 | 600 VAC | 850 VDC | 12 | A | Flange | Aviation Communication Systems Industrial | ||
TE Connectivity AMP Connectors | Panel Mount | Receptacle Male Pins | Passivated | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 260 °C | -65 ░C | Gold | Metal | Environment Resistant | 13 | 98 | 600 VAC | 850 VDC | 10 | N (Normal) | Flange | Aviation Communication Systems Industrial | ||
 TE Connectivity AMP Connectors | Panel Mount | Receptacle Male Pins | Nickel | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 200 °C | -65 ░C | Gold | Metal | Environment Resistant | 19 | 32 | 600 VAC | 850 VDC | B | Bulkhead - Front Side Nut | Aviation Communication Systems Industrial | |||
TE Connectivity AMP Connectors | Free Hanging (In-Line) | Plug Male Pins | Passivated | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 260 °C | -65 ░C | Gold | Metal | Environment Resistant | 15 | 97 | 600 VAC | 850 VDC | 12 | N (Normal) | Aviation Communication Systems Industrial | Coupling Nut | ||
TE Connectivity AMP Connectors | Panel Mount | Receptacle Male Pins | Passivated | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 260 °C | -65 ░C | Gold | Metal | Environment Resistant | 600 VAC | 850 VDC | 56 | A | Flange | Aviation Communication Systems Industrial | 25-4 | |||
TE Connectivity AMP Connectors | Panel Mount | Receptacle Male Pins | Nickel | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 200 °C | -65 ░C | Gold | Metal | Environment Sealed | 15 | 18 | 600 VAC | 850 VDC | 18 | N (Normal) | Flange | Aviation Communication Systems Industrial | ||
TE Connectivity AMP Connectors | Free Hanging (In-Line) | Plug Female Sockets | Nickel | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 200 °C | -65 ░C | Gold | Metal | Environment Resistant | 15 | 18 | 600 VAC | 850 VDC | 18 | N (Normal) | Aviation Communication Systems Industrial | Coupling Nut | ||
 TE Connectivity AMP Connectors | ||||||||||||||||||||||||||||
TE Connectivity AMP Connectors | Free Hanging (In-Line) | Plug Female Sockets | Passivated | Copper Alloy | MIL-DTL-38999 Series III | Stainless Steel | Silver | 50 µin | 1.27 µm | Shielded | Threaded | Thermoplastic | Crimp | 260 °C | -65 ░C | Gold | Metal | Environment Resistant | 600 VAC | 850 VDC | 8 | N (Normal) | Aviation Communication Systems Industrial | Coupling Nut | 13-8 | |||
TE Connectivity AMP Connectors |
