627-M37 Series
Manufacturer: EDAC Inc.
Beta
⌘K
VERTICAL MACHINED D-SUB CONNECTORS ROHS COMPLIANT: YES
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Mounting Type | Number of Rows [custom] | Contact Finish Thickness | Connector Style | Material Flammability Rating | Current Rating (Amps) | Contact Finish | Contact Type | Number of Positions | Shell Size, Connector Layout | Shell Size, Connector Layout | Connector Type | Flange Feature | Features | Termination | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Through Hole | 2 | Flash | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Green | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám | Nickel Plated Steel | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Blue | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Board Lock Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám | Nickel Plated Steel | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | 15 µin | 0.38 µm | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Board Lock Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám | Nickel Plated Steel | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Board Lock Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám | Nickel Plated Steel | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | 15 µin | 0.38 µm | Nickel Plated Steel | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Green | Copper Alloy | Through Hole | 2 | Flash | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | Solder | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Copper Alloy | Through Hole | 2 | D-Sub | UL94 V-0 | 5 A | Gold | Signal | 37 | 4 | DC C | Plug Male Pins | Board Side (4-40) | Board Lock Grounding Indents Shielded | Solder | 30 Áin | 0.76 Ám |
