2342083 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
12POS HDR 90 DEG,HT,5.08MM PITCH
| Part | Mounting Type | Positions Per Level | Operating Temperature [Min] | Operating Temperature [Max] | Contact Tail Length | Contact Tail Length | Contact Mating Finish | Current - UL | Type | Housing Material | Header Orientation | Pitch [x] | Pitch [x] | Number of Levels | Termination Style | Voltage - UL | Features | Contact Material | Material Flammability Rating | Color | Insulation Height | Insulation Height | Number of Positions | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Through Hole | 12 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 12 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 23 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 23 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 4 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 4 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 16 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 16 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 14 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 14 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 13 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 13 | |
TE Connectivity Raychem Cable Protection | Through Hole | 11 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 11 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 15 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 15 | |
TE Connectivity Raychem Cable Protection | Through Hole | 20 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 20 | |
 TE Connectivity Raychem Cable Protection | Through Hole | 21 | -40 °C | 105 ░C | 0.102 in | 2.6 mm | Tin | 11 A | Header Male Pins Shrouded (4 Side) | Polyamide (PA) Nylon | 90° Right Angle | 0.2 in | 5.08 mm | 1 | Solder | 300 V | High Temp Housing | Copper Alloy | UL94 V-0 | Black | 8.66 mm | 0.341 in | 21 |
