AVT3232 Series
Manufacturer: Panasonic Electric Works
Beta
⌘K
SWITCH SNAP ACTION SPDT 3A 125V
| Part | Electrical Life | Release Force | Pretravel | Pretravel | Switch Function | Differential Travel | Differential Travel | Circuit | Mechanical Life | Operating Position | Operating Position | Actuator Type | Mounting Type | Overtravel | Overtravel | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - DC | Current Rating (Amps) | Voltage Rating - AC | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Electric Works | 50000 Cycles | 1.224 gf | 0.138 in | 3.5 mm | On-Mom | 1 mm | 0.04 in | SPDT | 500000 Cycles | 8.8 mm | 0.345 in | Lever Straight | Chassis Mount | 1.6 mm | 0.062 in | -25 °C | 85 °C | 30 V | 3 A | 125 V | Solder Lug |
