MUR2X100 Series

Catalog

DIODE MOD GP 1.2KV 100A SOT227

Part	Voltage - DC Reverse (Vr) (Max) [Max]	Technology	Package / Case	Speed [Min]	Mounting Type	Supplier Device Package	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Current - Average Rectified (Io) (per Diode)	Diode Configuration	Current - Reverse Leakage @ Vr	Reverse Recovery Time (trr)	Voltage - Forward (Vf) (Max) @ If [Max]	Speed
GeneSiC Semiconductor MUR2X100A12	1.2 kV	Standard	SOT-227-4 miniBLOC	200 mA 500 ns	Chassis Mount	SOT-227	175 ░C	-55 °C	100 A	2 Independent	25 µA
GeneSiC Semiconductor MUR2X100A02	200 V	Standard	SOT-227-4 miniBLOC		Chassis Mount	SOT-227	175 ░C	-55 °C	100 A	2 Independent	25 µA	75 ns	1 V	200 mA 500 ns
GeneSiC Semiconductor MUR2X100A04	400 V	Standard	SOT-227-4 miniBLOC		Chassis Mount	SOT-227	175 ░C	-55 °C	100 A	2 Independent	25 µA	90 ns	1.3 V	200 mA 500 ns
GeneSiC Semiconductor MUR2X100A10	1000 V	Standard	SOT-227-4 miniBLOC	200 mA 500 ns	Chassis Mount	SOT-227	175 ░C	-55 °C	100 A	2 Independent	25 µA
GeneSiC Semiconductor MUR2X100A06	600 V	Standard	SOT-227-4 miniBLOC	200 mA 500 ns	Chassis Mount	SOT-227	175 ░C	-55 °C	100 A	2 Independent	25 µA		1.5 V
