846-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 24POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Pitch | Pitch | Card Type | Number of Positions/Bay/Row | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Mounting Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Number of Positions | Contact Type | Read Out | Contact Material | Color | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 12 | 2 | 125 °C | -40 C | Wire Wrap | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Dual | Copper Alloy | Green | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | 125 °C | -40 C | Solder | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Single | Copper Alloy | Green | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 12 | 2 | 125 °C | -40 C | Solder | Board Edge Straddle Mount | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Dual | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Card Extender | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | 125 °C | -40 C | Wire Wrap | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Single | Copper Alloy | Green | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 12 | 2 | 125 °C | -40 C | Solder | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Dual | Copper Alloy | Green | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | 125 °C | -40 C | Solder | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Single | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | 125 °C | -40 C | Solder Eyelet(s) | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Single | Copper Alloy | Green | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 12 | 2 | 125 °C | -40 C | Wire Wrap | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Dual | Copper Alloy | Green | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | 125 °C | -40 C | Solder | Right Angle Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Single | Copper Alloy | Green | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 12 | 2 | 125 °C | -40 C | Solder Eyelet(s) | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 24 | Cantilever | Dual | Copper Alloy | Green | 0.25 Ám | 10 Áin |
