J01461A0 Series
Manufacturer: Telegartner Inc
Beta
⌘K
2.2-5 JCK STR FLNG SD/SD G9
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Body Finish | Voltage Rating | Center Contact Plating | Dielectric Material | Body Material | Frequency - Max [Max] | Connector Style | Mounting Feature | Ingress Protection | Cable Group | Fastening Type | Contact Termination | Shield Termination | Impedance | Number of Ports | Center Contact Material | Mounting Type | Housing Color | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Flange | IP68 - Dust Tight Waterproof | RG-401 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
 Telegartner Inc | 90 °C | -55 C | Silver | 750 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Bulkhead - Front Side Nut | IP68 - Dust Tight Waterproof | RG-405 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
 Telegartner Inc | 90 °C | -55 C | Silver | 750 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | IP68 - Dust Tight Waterproof | RG-405 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Free Hanging (In-Line) | Silver | Female Socket Jack | |
Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | IP68 - Dust Tight Waterproof | RG-402 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Free Hanging (In-Line) | Silver | Female Socket Jack | |
Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Flange | IP68 - Dust Tight Waterproof | RG-402 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Bulkhead - Front Side Nut | IP68 - Dust Tight Waterproof | RG-402 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | IP68 - Dust Tight Waterproof | RG-401 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Free Hanging (In-Line) | Silver | Female Socket Jack | |
Telegartner Inc | 90 °C | -55 C | Silver | 1000 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Bulkhead - Front Side Nut | IP68 - Dust Tight Waterproof | RG-401 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
Telegartner Inc | 90 °C | -55 C | Silver | 750 VDC | Silver | Polytetrafluoroethylene (PTFE) | Copper Alloy | 6000 MHz | 2.2/5 | Flange | IP68 - Dust Tight Waterproof | RG-405 | Threaded | Solder | Solder | 50 Ohms | 1 | Beryllium Copper | Panel Mount | Silver | Female Socket Jack |
