171814 Series

Manufacturer: Molex

Catalog

KK RPC 156 HDR ASSY FRLK RA 04 C

Part	Connector Type	Number of Positions	Number of Rows	Number of Positions Loaded	Insulation Height	Insulation Height	Contact Length - Mating	Contact Length - Mating	Contact Finish - Post	Mounting Type	Contact Material	Insulation Color	Material Flammability Rating	Fastening Type	Contact Shape	Shrouding	Insulation Material	Contact Type	Contact Length - Post	Contact Length - Post	Style	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Termination	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications
Molex 1718142004
Molex 1718141005	Header	5	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable	Gold	0.38 µm	15 µin	3.96 mm	0.156 in	Solder
Molex 1718144007	Header	7	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable	Gold	0.38 µm	15 µin	3.96 mm	0.156 in	Solder	2.54 µm	100 µin	Automotive General Purpose Industrial Medical Telecommunications
Molex 1718140011	Header	11	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable		1.52 Ám	60 µin	3.96 mm	0.156 in	Solder	1.52 µm	60 µin	Automotive General Purpose Industrial Medical Telecommunications
Molex 1718142006
Molex 1718141008	Header	8	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable	Gold	0.38 µm	15 µin	3.96 mm	0.156 in	Solder	2.54 µm	100 µin	Automotive General Purpose Industrial Medical Telecommunications
Molex 1718141012	Header	12	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable	Gold	0.38 µm	15 µin	3.96 mm	0.156 in	Solder	2.54 µm	100 µin	Automotive General Purpose Industrial Medical Telecommunications
Molex 1718144003	Header		1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable	Gold	0.38 µm	15 µin	3.96 mm	0.156 in	Solder
Molex 1718142008
Molex 1718140009	Header	9	1	All	10 mm	0.394 "	0.446 in	11.33 mm	Tin	Right Angle Through Hole	Brass	Black	UL94 V-2	Friction Lock	Square	Shrouded - 1 Wall	Nylon Polyamide (PA)	Male Pin	0.1 in	2.54 mm	Board to Board Cable		1.52 Ám	60 µin	3.96 mm	0.156 in	Solder	1.52 µm	60 µin	Automotive General Purpose Industrial Medical Telecommunications
