746285 Series

Catalog

CONN RCPT 16P IDC 26-28AWG GOLD

Part	Contact Type	Wire Type	Color	Cable Termination	Row Spacing	Row Spacing	Contact Finish	Number of Rows [custom]	Mounting Type	Number of Positions	Pitch	Pitch	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Features	Number of Positions [custom]
TE Connectivity AMP Connectors 746285-3	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	16	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-4	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	20	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-1	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	10	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-9	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	40	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-2	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	14	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-5	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)	24	0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key
TE Connectivity AMP Connectors 746285-8	Forked	Ribbon Cable	Black	IDC	2.54 mm	0.1 "	Gold	2	Free Hanging (In-Line)		0.1 "	2.54 mm	0.38 µm	15 µin	Receptacle	Feed Through Polarizing Key	34
