178-015 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG/RCPT 15P RA SLDR
| Part | Dielectric Material | Contact Material | Color | Contact Form | Operating Temperature [Min] | Operating Temperature [Max] | Features | Material Flammability Rating | Contact Finish | Number of Positions | Number of Positions | Number of Rows [custom] | Connector Style | Connector Type | Current Rating (Amps) | Shell Material, Finish | Backset Spacing | Backset Spacing | Contact Finish Thickness | Termination | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Flange Feature | Contact Type | Mounting Type | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | |
NorComp Inc. | Polyester Glass Filled | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Receptacle Female Sockets | 5 A | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | ||
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | Housing/Shell | Signal | Panel Mount Right Angle Through Hole | 4-40 |
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | |
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | Housing/Shell | Signal | Panel Mount Right Angle Through Hole | 4-40 |
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | |
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Board Lock Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | Housing/Shell | Signal | Panel Mount Right Angle Through Hole | 4-40 |
NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | |
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | Black | Stamped | -55 C | 105 ░C | Board Lock Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins Receptacle Female Sockets | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole | ||
NorComp Inc. | Nylon 9T Polyamide (PA9T) | Brass | Black | Stamped | -55 C | 105 ░C | Grounding Indents Shielded | UL94 V-0 | Gold | 15 | 15 | 2 | D-Sub - Stacked | Plug Male Pins | 5 A | Nickel Plated Steel | 8.08 mm | 0.318 " | Flash | Solder | 2 | 2 | 4-40 Mating Side Female Screwlock | Signal | Panel Mount Right Angle Through Hole |
