V15H16 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION SPDT 16A 125V
| Part | Release Force | Operating Position | Operating Position | Voltage Rating - AC | Circuit | Differential Travel | Differential Travel | Operating Force | Termination Style | Current Rating (Amps) | Switch Function | Overtravel [custom] | Overtravel [custom] | Mechanical Life | Pretravel | Pretravel | Actuator Type | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 50 gf | 14.7 mm | 0.579 in | 125 V | SPDT | 0.5 mm | 0.02 in | 0.2 kgf | Quick Connect - 0.250" (6.3mm) | 16 A | On-Mom | 0.03 " | 0.76 mm | 1000000 Cycles | 0.06 in | 1.5 mm | Round (Pin Plunger) | Chassis Mount | 150 °C | -25 °C | |
 Honeywell Sensing and Productivity Solutions | 125 V | SPDT | Quick Connect - 0.250" (6.3mm) | 16 A | On-Mom | 1000000 Cycles | Lever Roller | Chassis Mount | 150 °C | -25 °C | |||||||||||
 Honeywell Sensing and Productivity Solutions | 10 gf | 20.6 mm | 0.812 in | 250 V | SPDT | 1.2 mm | 0.047 in | 60 gf | Quick Connect - 0.250" (6.3mm) | 16 A | On-Mom | 0.051 " | 1.3 mm | 5000000 Cycles | 0.125 in | 3.2 mm | Lever Roller | Chassis Mount | 150 °C | -25 °C | 50000 Cycles |
 Honeywell Sensing and Productivity Solutions | 20 gf | 20.6 mm | 0.812 in | 250 V | SPDT | 0.4 mm | 0.016 in | 120 gf | Quick Connect - 0.250" (6.3mm) | 16 A | On-Mom | 0.03 " | 0.76 mm | 5000000 Cycles | 0.063 in | 1.6 mm | Lever Roller | Chassis Mount | 150 °C | -25 °C | 50000 Cycles |
 Honeywell Sensing and Productivity Solutions | |||||||||||||||||||||
Honeywell Sensing and Productivity Solutions | 60 gf | 20.6 mm | 0.812 in | 250 V | SPDT | 0.4 mm | 0.016 in | 350 gf | Quick Connect - 0.250" (6.3mm) | 16 A | On-Mom | 0.03 " | 0.76 mm | 1000000 Cycles | 0.063 in | 1.6 mm | Lever Roller | Chassis Mount | 150 °C | -25 °C | 50000 Cycles |
