LCB Series

Catalog

TERMINALS COPPER 1 HOLE LONG BARREL WITH INSPECTIO

Part	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Contact Material	Contact Finish	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Color	Termination	Terminal Type	Wire Gauge	Length - Overall [x]	Length - Overall [x]	Width - Outer Edges [x]	Width - Outer Edges [x]	Terminal Style	Insulation	Tab Thickness	Tab Thickness	Mounting Type	Stud/Tab Size	Diameter - Ring ID	Diameter - Ring ID	Width - Outer Edges	Width - Outer Edges	Diameter - Barrel ID	Diameter - Barrel ID	Wire Gauge [Min]	Wire Gauge [Max]	Tab Thickness [custom]	Tab Thickness [custom]
Panduit Corp LCB1/0-38W-X	10.41 mm	0.41 "	0.39 in	9.91 mm	Copper	Electro-Tin	0.52 in	13.21 mm	Pink	Barrel Crimp	Rectangular Tongue	44 AWG	2.57 in	65.28 mm	0.76 "	19.3 mm	Single Stud Hole	Non-Insulated	0.12 in	3.05 mm	Free Hanging (In-Line)	0.375 Stud
Panduit Corp LCB2-56WH-Q			0.31 in	7.87 mm	Copper	Electro-Tin	0.42 in	10.67 mm	Brown	Barrel Crimp	Rectangular Tongue	2 AWG					Single Stud Hole	Non-Insulated	0.1 in	2.54 mm	Free Hanging (In-Line)	0.3125 Stud	8.64 mm	0.34 in	16.76 mm	0.66 in
Panduit Corp LCB1/0-12WF-X			0.39 in	9.91 mm	Copper	Electro-Tin	0.52 in	13.21 mm	Pink	Barrel Crimp	Rectangular Tongue	44 AWG					Single Stud Hole	Non-Insulated	0.12 in	3.05 mm	Free Hanging (In-Line) Right Angle	0.5 Stud	13.46 mm	0.53 in	20.32 mm	0.8 in
Panduit Corp LCB4-12WF-L					Copper	Electro-Tin	0.38 in	9.65 mm	Gray	Barrel Crimp	Rectangular Tongue				0.75 in	19.05 mm	Single Stud Hole	Non-Insulated	0.07 in	1.78 mm	Free Hanging (In-Line) Right Angle	0.5 Stud	13.46 mm	0.53 in			7.11 mm	0.28 in	2 AWG	4 AWG
Panduit Corp LCB4-56F-L					Copper	Electro-Tin	0.38 in	9.65 mm	Gray	Barrel Crimp	Rectangular Tongue						Single Stud Hole	Non-Insulated	0.07 in	1.78 mm	Free Hanging (In-Line) Right Angle	0.3125 Stud	8.64 mm	0.34 in	15.75 mm	0.62 in	7.11 mm	0.28 in	2 AWG	4 AWG
Panduit Corp LCB1/0-56W-X			0.39 in	9.91 mm	Copper	Electro-Tin	0.52 in	13.21 mm	Pink	Barrel Crimp	Rectangular Tongue	44 AWG	2.5 "	63.5 mm	0.76 "	19.3 mm	Single Stud Hole	Non-Insulated	0.12 in	3.05 mm	Free Hanging (In-Line)	0.3125 Stud	8.64 mm	0.34 in
Panduit Corp LCB350-12W-X
Panduit Corp LCB6-14F-L									Blue	Barrel Crimp	Rectangular Tongue	6 AWG			0.48 "	12.19 mm	Single Stud Hole	Non-Insulated	0.08 "	2.03 mm	Free Hanging (In-Line) Right Angle	0.25 Stud
Panduit Corp LCB1-12WH-E			0.36 in	9.14 mm	Copper	Electro-Tin	0.47 "	11.94 mm	Green	Barrel Crimp	Rectangular Tongue	1 AWG			0.75 in	19.05 mm	Single Stud Hole	Non-Insulated			Free Hanging (In-Line)	0.5 Stud	13.46 mm	0.53 in							0.09 in	2.29 mm
Panduit Corp LCB1-12W-E			0.36 in	9.14 mm	Copper	Electro-Tin	0.47 "	11.94 mm	Green	Barrel Crimp	Lug Grounding	1 AWG	2.7 in	68.58 mm	0.75 in	19.05 mm	Single Stud Hole	Non-Insulated			Free Hanging (In-Line)	0.5 Stud	13.46 mm	0.53 in							0.09 in	2.29 mm
