627-8W8 Series
Manufacturer: EDAC Inc.
Beta
⌘K
COMBINATION LAYOUT D SUB CONNECTOR, 627C SERIES, DC-8W8, PLUG, 8 CONTACTS, 8 COAX, SOLDER CUP
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Voltage Rating | Number of Rows | Number of Positions | Mounting Type | Contact Type | Material Flammability Rating | Connector Type | Flange Feature | Features | Shell Size, Connector Layout [x] | Shell Size, Connector Layout | Connector Style | Contact Finish | Shell Material, Finish | Contact Finish Thickness | Termination | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Free Hanging (In-Line) | Coax | UL94 V-0 | Plug Male Pins | Board Side (M3) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Nickel Plated Steel | Flash | ||||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Free Hanging (In-Line) | Coax | UL94 V-0 | Plug Male Pins | Housing/Shell (Unthreaded) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Nickel Plated Steel | Flash | ||||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Panel Mount Through Hole | Power | UL94 V-0 | Plug Male Pins | M3 | Board Lock Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Flash | Solder | 30 A | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Panel Mount | Coax | UL94 V-0 | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Nickel Plated Steel | Solder | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Through Hole | Power | UL94 V-0 | Plug Male Pins | Board Side (M3) | Board Lock Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Solder | 20 A | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Panel Mount | Coax | UL94 V-0 | Plug Male Pins | Board Side (M3) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Solder | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Free Hanging (In-Line) | Power | UL94 V-0 | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Nickel Plated Steel | Flash | 10 A | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Panel Mount | Power | UL94 V-0 | Plug Male Pins | Board Side (4-40) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Flash | Solder | 20 A | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Panel Mount Through Hole | Coax | UL94 V-0 | Plug Male Pins | 4-40 | Board Lock Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | Solder | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Black | 125 VDC | 1 | 8 | Free Hanging (In-Line) | Power | UL94 V-0 | Plug Male Pins | Housing/Shell (Unthreaded) | Grounding Indents Shielded | 4 | 8W8 C DC | Combo D-Sub | Gold | 30 A | 30 Áin | 0.76 Ám |
