633-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
633 SERIES RIGHT ANGLE D-SUB PLU
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Number of Rows [custom] | Shell Material, Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Mounting Type | Connector Type | Backset Spacing | Backset Spacing | Current Rating (Amps) | Connector Style | Contact Finish | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Features | Termination | Flange Feature | Number of Positions | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | 30 Áin | 0.76 Ám | Signal | Grounding Indents Mounting Brackets Shielded | Solder | 4-40 Mating Side Female Screwlock | 26 | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | 30 Áin | 0.76 Ám | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (Unthreaded) | 26 | ||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | 26 | Flash | 4-40 | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | 15 µin | 0.38 µm | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | 26 | 4-40 | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Grounding Indents Mounting Brackets Shielded | Solder | 4-40 | 26 | Flash | |||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (Unthreaded) | 26 | Flash | |||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (Unthreaded) | 26 | Flash | |||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | 4-40 Mating Side Female Screwlock | 26 | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | 30 Áin | 0.76 Ám | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | 26 | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | 3 | Nickel Plated Steel | 2 | DA A | Board Edge Right Angle Through Hole | Plug Male Pins | 8.89 mm | 0.35 in | 3 A | D-Sub High Density | Gold | UL94 V-0 | Signal | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | 4-40 | 26 | Flash |
