CI3302P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
CONN HEADER VERT 2POS 2.54MM
| Part | Pitch - Mating | Pitch - Mating | Mounting Type | Insulation Color | Number of Positions | Number of Rows | Contact Finish - Post | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Height | Insulation Height | Style | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shrouding | Contact Type | Voltage Rating | Connector Type | Termination | Contact Shape | Current Rating (Amps) | Contact Material | Fastening Type | Number of Positions Loaded | Insulation Material | Contact Length - Post [x] | Contact Length - Post | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 0.1 " | 2.54 mm | Through Hole | Black | 2 | 1 | Tin | -40 C | 105 ░C | 11.5 mm | 0.453 in | Board to Cable/Wire | 120 µin | 3.05 µm | Shrouded - 4 Wall | Male Pin | 250 VAC | Header | Solder | Square | 3 A | Brass | Latch Holder | All | Glass Filled Nylon Polyamide (PA) | 0.134 " | 3.4 mm | UL94 V-0 |
