HEG.1K Series

Manufacturer: LEMO

Catalog

CONN RCPT FMALE 4P GOLD SLDR CUP

Part	Primary Material	Applications	Orientation [custom]	Shell Size - Insert	Shell Finish	Current Rating (Amps)	Shell Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Color	Number of Positions	Connector Type	Ingress Protection	Mounting Feature	Insert Material	Features	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Shielding	Mounting Type	Contact Material	Contact Finish - Mating	Material Flammability Rating	Termination	Shell Size - Insert [custom]	Shell Size - Insert [custom]
LEMO HEG.1K.304.CLLPV	Metal	Aviation Military	G	304	Chrome	10 A	Brass	1.5 Ám	59 Áin	Silver	4	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted Vacuumtight	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
LEMO HEG.1K.314.CLLPV	Metal	Aviation Military	G	314	Chrome	2 A	Brass	1.5 Ám	59 Áin	Silver	14	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted Vacuumtight	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
LEMO HEG.1K.314.CLNP	Metal	Aviation Military	G	314	Chrome	2 A	Brass	1.5 Ám	59 Áin	Silver	14	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount Through Hole	Bronze	Gold	UL94 V-0	Solder
LEMO HEG.1K.310.CLLPV	Metal	Aviation Military	G	310	Chrome	2.5 A	Brass	1.5 Ám	59 Áin	Silver	10	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted Vacuumtight	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
LEMO HEG.1K.303.CLLP	Metal	Aviation Military	G	303	Chrome	12 Amps	Brass	1.5 Ám	59 Áin	Silver		Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
LEMO HEG.1K.302.CLLPV	Metal	Aviation Military	G	302	Chrome	15 A	Brass	1.5 Ám	59 Áin	Silver	2	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted Vacuumtight	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
LEMO HEG.1K.307.CLNP	Metal	Aviation Military	G		Chrome	7 A	Brass	1.5 Ám	59 Áin	Silver	7	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount Through Hole	Bronze	Gold	UL94 V-0	Solder	307
LEMO HEG.1K.316.CLNPV	Metal	Aviation Military	G		Chrome	1.5 A	Brass	1.5 Ám	59 Áin	Silver	16	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted Vacuumtight	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount Through Hole	Bronze	Gold	UL94 V-0	Solder		316
LEMO HEG.1K.316.KLLP	Metal	Aviation Military	G			1.5 A	Brass	1.5 Ám	59 Áin	Black	16	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0			316
LEMO HEG.1K.314.CLLP	Metal	Aviation Military	G	314	Chrome	2 A	Brass	1.5 Ám	59 Áin	Silver	14	Receptacle Female Sockets	IP68 - Dust Tight Waterproof	Bulkhead - Front Side Nut	Polyetheretherketone (PEEK)	Potted	-20 ░C	100 °C	Push-Pull	Shielded	Panel Mount	Bronze	Gold	UL94 V-0
