NEOHM EP Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

Catalog

EP 4W (SS) 330R 5%

...

Part	Supplier Device Package	Tolerance	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [diameter]	Size / Dimension [x]	Composition	Features	Power (Watts)	Temperature Coefficient	Operating Temperature [Max]	Operating Temperature [Min]	Resistance	Number of Terminations [custom]	Package / Case	Temperature Coefficient	Size / Dimension [z]	Size / Dimension [z]
TE Connectivity AMP Connectors EP4WSS330RJ	Axial	5 %	15.5 mm	5.5 mm	0.217 in	0.61 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	4 W	300 ppm/°C	155 C	-55 C	330 Ohms	2	Axial
TE Connectivity AMP Connectors EP1WSS51RJ	Axial	5 %	9 mm	3 mm	0.118 in	0.354 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	1 W	300 ppm/°C	155 C	-55 C	51 Ohms	2	Axial
TE Connectivity AMP Connectors EP1WS22RJ	Axial	5 %	10 mm	3.5 mm	0.138 in	0.394 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	1 W	300 ppm/°C	155 C	-55 C	22 Ohms	2	Axial
TE Connectivity AMP Connectors EP10WSS240RJBB	Axial	5 %	40 mm	8.5 mm	0.335 in	1.575 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	10 W	300 ppm/°C	155 C	-55 C	240 Ohms	2	Axial
TE Connectivity AMP Connectors EP4WSS1R1J	Axial	5 %	15.5 mm	5.5 mm	0.217 in	0.61 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	4 W		155 C	-55 C	1.1 Ohms	2	Axial	±400ppm/°C
TE Connectivity AMP Connectors EP7W470RJ	Axial	5 %	30 mm	8.5 mm	0.335 in	1.181 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	7 W	300 ppm/°C	155 C	-55 C	470 Ohms	2	Axial
TE Connectivity AMP Connectors EP1WSSS6R8J	Axial	5 %		2.5 mm	0.098 in		Wirewound	Flame Retardant Coating Pulse Withstanding Safety	1 W		155 C	-55 C	6.8 Ohms	2	Axial	±400ppm/°C	6.8 mm	0.268 "
TE Connectivity AMP Connectors EP4WSS2R7J	Axial	5 %	15.5 mm	5.5 mm	0.217 in	0.61 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	4 W		155 C	-55 C	2.7 Ohms	2	Axial	±400ppm/°C
TE Connectivity AMP Connectors EP1WS33RJ	Axial	5 %	10 mm	3.5 mm	0.138 in	0.394 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	1 W	300 ppm/°C	155 C	-55 C	33 Ohms	2	Axial
TE Connectivity AMP Connectors EP4WSS82RJ	Axial	5 %	15.5 mm	5.5 mm	0.217 in	0.61 in	Wirewound	Flame Retardant Coating Pulse Withstanding Safety	4 W	300 ppm/°C	155 C	-55 C	82 Ohms	2	Axial
