RP182CS Series

Catalog

LINE FILTER 250VAC 10A CHASSIS

Part	Configuration	Current	Frequency - Operating [Max]	Frequency - Operating [Min]	Filter Type	Mounting Type	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated AC	Termination Style	Approval Agency
Astrodyne TDI RP182CS-10-4.7-W	Single Stage	10 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Wire Leads	CE CSA SEMKO UR
Astrodyne TDI RP182CS-6-4.7-W	Single Stage	6 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Wire Leads	CE CSA SEMKO UR
Astrodyne TDI RP182CS-3-.47-QD	Single Stage	3 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-6-.47-QD	Single Stage	6 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-3-0-QD	Single Stage	3 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-6-4.7-QD	Single Stage	6 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-10-4.7-QD	Single Stage	10 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-3-2.2-QD	Single Stage	3 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-6-0-QD	Single Stage	6 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
Astrodyne TDI RP182CS-10-.47-QD	Single Stage	10 A	60 Hz	50 Hz	Single Phase	Chassis Mount	General Purpose	100 °C	-25 °C	250 V	IEC 320-C14 Quick Connect	CE CSA SEMKO UR
