887-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row | Termination | Gender | Mounting Type | Color | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Pitch | Pitch | Read Out | Features | Number of Positions | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder | Female | Board Edge Straddle Mount | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | Card Extender | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 125 °C | -40 C | Gold | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Gold | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder Eyelet(s) | Female | Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 2 | 29 | Solder | Female | Right Angle Through Hole | Black | 0.25 Ám | 10 Áin | Copper Alloy | 3.96 mm | 0.156 in | Dual | 58 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Gold |
