N-7 Series
Manufacturer: Essentra Components
Beta
⌘K
FASTENER, SCREW MOUNT CABLE CLAMP, 11.1 MM, NYLON 6.6 (POLYAMIDE 6.6), BLACK, 12.7 MM
| Part | Screw Size | Screw Size | Bundle Center to Mounting Center | Bundle Center to Mounting Center | Material Thickness | Material Thickness | Color | Material Flammability Rating | Opening Size | Opening Size | Panel Hole Size | Panel Hole Size | Width | Width | Mounting Type | Type | Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Essentra Components | M5 | #10 | 13.5 mm | 0.531 " | 0.063 in | 1.6 mm | Black | UL94 V-2 | 11.13 mm | 0.438 " | 0.204 in | 5.18 mm | 12.7 mm | 0.5 in | Fastener | Clamp P-Type | Polyamide (PA66) Nylon 6/6 | |
 Essentra Components | M5 | #10 | 13.5 mm | 0.531 " | 0.063 in | 1.6 mm | Natural | UL94 V-2 | 11.13 mm | 0.438 " | 0.204 in | 5.18 mm | 12.7 mm | 0.5 in | Fastener | Clamp P-Type | Polyamide (PA66) Nylon 6/6 | |
 Essentra Components | M5 | #10 | 13.5 mm | 0.531 " | 0.063 in | 1.6 mm | Natural | UL94 V-0 | 11.13 mm | 0.438 " | 0.204 in | 5.18 mm | 12.7 mm | 0.5 in | Fastener | Clamp P-Type | Polyamide (PA66) Nylon 6/6 | Flame Retardant |
