51AAA Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 100K OHM 1W CERMET LINEAR
| Part | Mounting Type | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Taper | Features | Resistive Material | Tolerance | Number of Turns | Termination Style | Resistance (Ohms) | Rotation | Actuator Type | Temperature Coefficient | Adjustment Type | Actuator Length [x] | Actuator Length [x] | Number of Gangs | Bushing Thread | Power (Watts) | Size - Body [y] | Size - Body [x] | Size - Body [y] | Size - Body [x] | Built in Switch | Power (Watts) | Resistance (Ohms) | Resistance (Ohms) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Cermet | 10 % | 1 | PC Pins | 100k | 290 ° | Slotted | 150 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 1 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | |||
 Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 10k | 290 ° | Slotted | 1000 ppm/°C | Side Adjustment | 22.23 mm | 0.875 in | 1 | 3/8-32 | 0.5 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.5 W | ||
 Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 10k | 290 ° | Flatted | 1000 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 0.5 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.5 W | ||
 Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Logarithmic | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 10k | 290 ° | Slotted | 1000 ppm/°C | Side Adjustment | 22.23 mm | 0.875 in | 1 | 3/8-32 | 0.25 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.25 W | ||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 290 ° | Slotted | 1000 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 0.5 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.5 W | 5 kOhms | ||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Cermet | 10 % | 1 | PC Pins | 1k | 290 ° | Slotted | 150 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 1 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | |||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Logarithmic | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 290 ° | Slotted | 1000 ppm/°C | Side Adjustment | 22.23 mm | 0.875 in | 1 | 3/8-32 | 0.25 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.25 W | 50 kOhms | ||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Conductive Plastic | 20 % | 1 | PC Pins | 290 ° | Slotted | 1000 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 0.5 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 0.5 W | 50 kOhms | ||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Cermet | 10 % | 1 | PC Pins | 290 ° | Slotted | 150 ppm/°C | Side Adjustment | 22.23 mm | 0.875 in | 1 | 3/8-32 | 1 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 50 kOhms | |||
Bourns Inc. | Panel Mount | 6.35 mm | 0.25 in | Linear | Sealed | Cermet | 10 % | 1 | PC Pins | 290 ° | Slotted | 150 ppm/°C | Side Adjustment | 19.05 mm | 0.75 in | 1 | 3/8-32 | 1 W | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | None | 50 kOhms |
