208033 Series
ConnTAK50 Header, Single Row, Right-Angle, Surface Mount, 6 Circuits, Key C, Blue
Manufacturer: Molex
Catalog
ConnTAK50 Header, Single Row, Right-Angle, Surface Mount, 6 Circuits, Key C, Blue
Beta
⌘K
ConnTAK50 Header, Single Row, Right-Angle, Surface Mount, 6 Circuits, Key C, Blue
ConnTAK50 Header, Single Row, Right-Angle, Surface Mount, 6 Circuits, Key C, Blue
ConnTAK50 Header, Single Row, Right-Angle, Surface Mount, 6 Circuits, Key C, Blue
| Part | Insulation Material | Number of Rows | Insulation Color | Shrouding | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Type | Termination | Contact Shape | Voltage Rating | Material Flammability Rating | Contact Material | Current Rating (Amps) | Number of Positions Loaded | Connector Type | Pitch - Mating | Pitch - Mating | Style | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Insulation Height [z] | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | |||||||||||||||||||||||||
 Molex | Polyamide (PA9T) Nylon 9T Glass Filled | 1 | Natural | Shrouded - 4 Wall | Surface Mount Right Angle | 1 µm | 39.4 µin | Male Pin | Solder | Square | 14 VAC/DC | UL94 V-0 | Brass | Varies by Wire Gauge | All | Header | 0.071 in | 1.8 mm | Board to Cable/Wire | Latch Holder | -40 °C | 105 ░C | 4 | 0.253 in | 6.43 mm |
