R5F572 Series

High Performance Real-time Engine 32-bit Microcontrollers for Industrial Equipment

Manufacturer: Renesas Electronics Corporation

Catalog

High Performance Real-time Engine 32-bit Microcontrollers for Industrial Equipment

...

Part	EEPROM Size	Core Processor	Core Size	Program Memory Size	Mounting Type	Data Converters	Package / Case	Program Memory Type	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Number of I/O	Operating Temperature [Max]	Operating Temperature [Min]	RAM Size	Supplier Device Package	Speed	Oscillator Type	Connectivity	Peripherals
Renesas Electronics Corporation R5F571MLCDFB#30	64 K	RXv2	32-Bit Single-Core	4 MB	Surface Mount	A/D 21x12b A/D 8x12b D/A 2x12b	144-LQFP	FLASH	3.6 V	2.7 V	111	85 °C	-40 °C	512 K	144-LFQFP (20x20)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F571MGCGFP#V0	64 K	RXv2	32-Bit	2.5 MB	Surface Mount	A/D 22x12b D/A 1x12b	100-LQFP	FLASH	3.6 V	2.7 V	78	105 °C	-40 °C	512 K	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet FIFO I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F572NNHGFB#30	32 K	RXv3	32-Bit	4 MB	Surface Mount		144-LQFP	FLASH	3.6 V	2.7 V	111	105 °C	-40 °C	1 M	144-LFQFP (20x20)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LCD LVD POR PWM WDT
Renesas Electronics Corporation R5F571MLCGFP#V0	64 K	RXv2	32-Bit	4 MB	Surface Mount	A/D 22x12b D/A 1x12b	100-LQFP	FLASH	3.6 V	2.7 V	78	105 °C	-40 °C	512 K	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet FIFO I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F572NNHDFP#30	32 K	RXv3	32-Bit Single-Core	4 MB	Surface Mount	A/D 22x12b D/A 1x12b	100-LQFP	FLASH	3.6 V	2.7 V	78	85 °C	-40 °C	1 M	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LCD LVD POR PWM WDT
Renesas Electronics Corporation R5F572TFADFP#30	32 K	RXv3	32-Bit Single-Core	512 KB	Surface Mount	A/D 24x12b D/A 2x12b	100-LQFP	FLASH	5.5 V	2.7 V	72	85 °C	-40 °C	128 K	100-LFQFP (14x14)	200 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F572NDHGBD#20	32 K	RXv3	32-Bit	2 MB	Surface Mount		224-LFBGA	FLASH	3.6 V	2.7 V	182	105 °C	-40 °C	1 M	224-LFBGA (13x13)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LCD LVD POR PWM WDT
Renesas Electronics Corporation R5F571MFDDFP#30	64 K	RXv2	32-Bit Single-Core	2 MB	Surface Mount	A/D 14x12b A/D 8x12b D/A 1x12	100-LQFP	FLASH	3.6 V	2.7 V	78	85 °C	-40 °C	512 K	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F572MNHDFP#10	32 K	RXv3	32-Bit	4 MB	Surface Mount		100-LQFP	FLASH	3.6 V	2.7 V	72	85 °C	-40 °C	1 M	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT
Renesas Electronics Corporation R5F571MJDGFP#V0	64 K	RXv2	32-Bit	3 MB	Surface Mount	A/D 22x12b D/A 1x12b	100-LQFP	FLASH	3.6 V	2.7 V	78	105 °C	-40 °C	512 K	100-LFQFP (14x14)	240 MHz	Internal	CANbus EBI/EMI Ethernet FIFO I2C MMC/SD QSPI SCI SPI SSI USB OTG	DMA LVD POR PWM WDT

Catalog

High Performance Real-time Engine 32-bit Microcontrollers for Industrial Equipment

Description

32-bit microcontroller capable of up to 240 MHz operation. Employs the RXv2 core, a more powerful evolved form of the RX core that was used in previous RX devices, while maintaining compatibility. Realizes 1160 CoreMark, the top performance among microcontrollers with built-in flash. Cache optimized for flash memory (AFU) can realize equivalent of 240-MHz zero wait flash memory access. The wait time for the CPU is a mere 1 cycle thanks to the 120-MHz zero wait access flash memory. This extremely high-speed memory access brings out the full performance of the CPU. Built-in AES, DES, SHA, and RNG protect data on a network. Built-in trusted memory function forbids reading of code from a specified area of the built-in flash memory. Equipped with up to 4 MB of code ROM and 552 KB of work RAM to support the increasing code/work area demanded by IoT network control and other applications.
