346-022 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FMALE 22POS 0.125
...
| Part | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Termination Rows | Number of Rows | Termination | Gender | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Color | Material - Insulation | Pitch [x] | Pitch [x] | Card Type | Contact Type | Contact Material | Read Out | Features | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Mounting Type | Number of Positions/Bay/Row [custom] | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 1 | Wire Wrap | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Single Edge | Cantilever | Copper Alloy | Single | Card Guides | 10 Áin | 0.25 Ám | 4-40 Threaded Insert Top Mount Opening | Through Hole | 22 | Gold | ||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 1 | Solder | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Single Edge | Cantilever | Copper Alloy | Single | 10 Áin | 0.25 Ám | Floating Bobbin Flush Mount | Through Hole | 22 | Gold | 0.116 in | 2.95 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 1 | Solder | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Single Edge | Cantilever | Copper Alloy | Single | 10 Áin | 0.25 Ám | Flush Mount Side Opening Unthreaded | Through Hole | 22 | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 1 | Wire Wrap | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Single Edge | Cantilever | Copper Alloy | Single | 10 Áin | 0.25 Ám | Flush Mount Top Opening Unthreaded | Through Hole | 22 | Gold | 0.156 in | 3.96 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder Wire Wrap | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole Right Angle | 11 | Gold | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder Wire Wrap | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | Flush Mount M3 Threaded Insert Top Opening | Through Hole Right Angle | 11 | Gold | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | 4-40 Flush Mount Threaded Insert Top Opening | Board Edge Straddle Mount | 11 | Gold | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | Top Mount Opening Unthreaded | Through Hole | 11 | Gold | 0.156 in | 3.96 mm | |
EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder Wire Wrap | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | M3 Threaded Insert Top Mount Opening | Through Hole Right Angle | 11 | Gold | |||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 2 | Solder | Female | 22 positions | -40 °C | 105 ░C | Green | Polyester Thermoplastic | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Cantilever | Copper Alloy | Dual | 10 Áin | 0.25 Ám | M3 Threaded Insert Top Mount Opening | Through Hole | 11 | Gold |
