4310R Series

Catalog

RESISTOR NETWORKS & ARRAYS 10K 10PIN 2% ISOLATED

...

Part	Number of Resistors	Mounting Type	Temperature Coefficient	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Power Per Element	Circuit Type	Supplier Device Package	Resistor-Ratio-Drift	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Number of Pins	Resistance (Ohms)	Tolerance	Resistance (Ohms)	Tolerance	Resistance (Ohms) [custom]	Number of Resistors [custom]
Bourns Inc. 4310R-102-103	5	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	300 mW	Isolated	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10	10k	2 %
Bourns Inc. 4310R-102-330LF	5	Through Hole	250 ppm/°C	10-SIP	-55 C	125 °C	300 mW	Isolated	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10			33 Ohms	±1Ohm
Bourns Inc. 4310R-104-152/332L		Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	200 mW	Dual Terminator	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10		2 %			1.5 kOhms 3.3 kOhms	16
Bourns Inc. 4310R-102-224	5	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	300 mW	Isolated	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10		2 %	220 kOhms
Bourns Inc. 4310R-101-560LF	9	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	200 mW	Bussed	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10		2 %			56 Ohms
Bourns Inc. 4310R-R2R-103LF		Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	125 mW	R2R Ladder	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10	10k 20k	2 %				16
Bourns Inc. 4310R-101-303LF	9	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	200 mW	Bussed	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10	30k	2 %
Bourns Inc. 4310R-102-330	5	Through Hole	250 ppm/°C	10-SIP	-55 C	125 °C	300 mW	Isolated	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10			33 Ohms	±1Ohm
Bourns Inc. 4310R-101-823LF	9	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	200 mW	Bussed	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10		2 %	82 kOhms
Bourns Inc. 4310R-102-563LF	5	Through Hole	100 ppm/°C	10-SIP	-55 C	125 °C	300 mW	Isolated	10-SIP	50 ppm/°C	4.95 mm	0.195 in	10		2 %	56 kOhms
