622-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
622 SERIES RIGHT ANGLE D-SUB REC
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Color | Dielectric Material | Contact Material | Current Rating (Amps) | Shell Size, Connector Layout | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Backset Spacing | Backset Spacing | Termination | Connector Type | Shell Material, Finish | Number of Rows [custom] | Contact Type | Contact Finish | Number of Positions | Connector Style | Flange Feature | Flange Feature | Features | Mounting Type | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.38 µm | 15 µin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell | 4-40 | Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | |
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell (M3) | Board Lock Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.38 µm | 15 µin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell | 4-40 | Board Lock Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | |
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.38 µm | 15 µin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell (M3) | Board Lock Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | 4-40 | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | 4-40 Mating Side Female Screwlock | Board Lock Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Flash | |||
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.76 Ám | 30 Áin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | 4-40 | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | -55 C | 85 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.38 µm | 15 µin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell (M3) | Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | -55 C | 125 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.76 Ám | 30 Áin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | 4-40 | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | ||
 EDAC Inc. | -55 C | 125 °C | Black | Polyester Thermoplastic | Copper Alloy | 3 A | 2 | UL94 V-0 | 0.38 µm | 15 µin | 8.08 mm | 0.318 " | Solder | Receptacle Female Sockets | Nickel Plated Steel | 2 | Signal | Gold | 15 | D-Sub | Housing/Shell (M3) | Board Lock Filter Mounting Brackets Shielded | Board Edge Right Angle Through Hole |
