CONN HEADER R/A 21POS 2.54MM

...

Part	Number of Positions	Current Rating (Amps)	Contact Material	Number of Rows	Contact Finish - Mating	Contact Shape	Contact Type	Shrouding	Fastening Type	Number of Positions Loaded	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Termination	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating	Pitch - Mating	Insulation Color	Connector Type	Insulation Height	Insulation Height	Voltage Rating	Contact Finish - Post	Insulation Material	Overall Contact Length	Overall Contact Length	Contact Length - Post	Contact Length - Post	Features
Preci-Dip 800-V3-021-20-001101	21	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Right Angle Through Hole	4.95 mm	0.195 in	0.126 "	3.2 mm	Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.1 in	2.54 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-005-40-001101	5	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Right Angle Surface Mount	4.85 mm	0.191 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.1 in	2.54 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-030-12-002101	30	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Through Hole	3.6 mm	0.141 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.272 in	6.91 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	9.8 mm	0.386 in	0.118 in	3 mm
Preci-Dip 800-V3-004-32-002191	4	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Surface Mount	3.6 mm	0.141 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.272 in	6.91 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester					Pick and Place
Preci-Dip 800-V3-028-32-002101	28	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Surface Mount	3.6 mm	0.141 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.272 in	6.91 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-005-30-001101	5	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Surface Mount	4.85 mm	0.191 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.116 "	2.95 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-026-40-001101	26	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Right Angle Surface Mount	4.85 mm	0.191 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.1 in	2.54 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-011-32-002101	11	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Surface Mount	3.6 mm	0.141 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.272 in	6.91 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-009-30-001101	9	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Surface Mount	4.85 mm	0.191 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.116 "	2.95 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
Preci-Dip 800-V3-012-40-001101	12	3 A	Brass	1	Gold	Circular	Male Pin	Unshrouded	Push-Pull	All	29.5 µin	0.75 µm	Right Angle Surface Mount	4.85 mm	0.191 in			Solder	UL94 V-0	-55 C	125 °C	0.1 "	2.54 mm	Black	Header	0.1 in	2.54 mm	150 VDC	Tin	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester
