1075A Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 5COND 20/22AWG
| Part | Shield Material | Shield Coverage | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Material | Jacket (Insulation) Material | Ratings | Conductor Insulation | Jacket Color | Wire Gauge | Number of Conductors | Conductor Strand [custom] | Conductor Strand [x] | Cable Type | Shield Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Length | Length | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | -30 ░C | 105 ░C | Copper Bare | Poly-Vinyl Chloride (PVC) | UL Style 2464 | Poly-Vinyl Chloride (PVC) | Black | 20 22 | 5 | 28 30 | 7 | Multi-Pair | Foil | 0.042 in | 1.067 mm | 4000 ' | 1219.2 m | Drain Wire Rip Cord | 9.27 mm | 0.365 in |
 Belden Inc. | Aluminum | 100 % | -30 ░C | 105 ░C | Copper Bare | Poly-Vinyl Chloride (PVC) | UL Style 2464 | Poly-Vinyl Chloride (PVC) | Black | 20 22 | 5 | 28 30 | 7 | Multi-Pair | Foil | 0.042 in | 1.067 mm | 10000 ft | 3048 m | Drain Wire Rip Cord | 9.27 mm | 0.365 in |
