9433-9113 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / STRAIGHT JACK RECEPTACLE F
| Part | Mating Cycles | Center Contact Plating | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Body Material | Center Contact Material | Fastening Type | Shield Termination | Housing Color | Connector Style | Frequency - Max [Max] | Contact Termination | Connector Type | Number of Ports | Mounting Type | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 500 | Gold | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Beryllium Copper | Threaded | Solder | Silver | SMA | 18 GHz | Solder Cup | Female Socket Jack | 1 | Free Hanging (In-Line) | 50 Ohms |
