Single N-Channel Power MOSFET 80V, 71A, 7mΩ
Key Features
• Small Footprint (3x3 mm)
• Low RDS(on)
• Low QG and Capacitance
• Wettable Flank Option available
• AEC−Q101 Qualified and PPAP Capable
• RoHS Compliant
Beta
⌘K
Single N-Channel Power MOSFET 80V, 71A, 7mΩ
Single N-Channel Power MOSFET 80V, 71A, 7mΩ
| Part | Grade | Technology | Input Capacitance (Ciss) (Max) @ Vds | Operating Temperature [Min] | Operating Temperature [Max] | Vgs (Max) | Drive Voltage (Max Rds On, Min Rds On) | FET Type | Package / Case | Vgs(th) (Max) @ Id | Current - Continuous Drain (Id) @ 25°C | Mounting Type | Rds On (Max) @ Id, Vgs | Qualification | Power Dissipation (Max) | Gate Charge (Qg) (Max) @ Vgs | Drain to Source Voltage (Vdss) | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ON Semiconductor | Automotive | MOSFET (Metal Oxide) | 1810 pF | -55 °C | 175 ░C | 20 V | 4.5 V 10 V | N-Channel | 8-PowerWDFN | 3 V | 14.4 A 71 A | Surface Mount | 7 mOhm | AEC-Q101 | 3.3 W 79 W | 32.5 nC | 80 V | 8-WDFN (3.3x3.3) |
 ON Semiconductor | Automotive | MOSFET (Metal Oxide) | 1810 pF | -55 °C | 175 ░C | 20 V | 4.5 V 10 V | N-Channel | 8-PowerWDFN | 3 V | 14.4 A 71 A | Surface Mount | 7 mOhm | AEC-Q101 | 3.3 W 79 W | 32.5 nC | 80 V | 8-WDFNW (3.3x3.3) |
