SWI25 Series

Manufacturer: CUI Inc.

Catalog

WALL MOUNT AC ADAPTERS 20W 5V 4A USA PLUG 2.1 DC PLUG

Part	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Form	Region Utilized	Power (Watts)	Current - Output (Max) [Max]	Applications	Cord Length	Cord Length	Output Connector	Output Connector [diameter]	Output Connector [x]	Efficiency	Input Type	Input Connector	Operating Temperature [Min]	Operating Temperature [Max]	Polarization	Voltage - Output	No Load Power Consumption	Voltage - Input [Max]	Voltage - Input [Min]	Standard Number	Approval Agency
CUI Inc. SWI25-5-N-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	North America	20 W	4 A	ITE (Commercial)	1.22 m	48 in	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	Level VI	Fixed Blade	NEMA 1-15P	-20 ░C	40 °C	Positive Center	5 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1
CUI Inc. SWI25-12-E-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	Europe	25 W	2.1 A	ITE (Commercial)	1.8 m	70.9 "	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	CoC Tier 2 Level VI	Fixed Blade	CEE 7/16	-20 ░C	40 °C	Positive Center	12 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1	EN FCC SIQ TUV
CUI Inc. SWI25-12-N-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	North America	25 W	2.1 A	ITE (Commercial)	1.8 m	70.9 "	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	Level VI	Fixed Blade	NEMA 1-15P	-20 ░C	40 °C	Positive Center	12 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1
CUI Inc. SWI25-5-E-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	Europe	20 W	4 A	ITE (Commercial)	1.22 m	48 in	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	CoC Tier 2 Level VI	Fixed Blade	CEE 7/16	-20 ░C	40 °C	Positive Center	5 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1	EN FCC SIQ TUV
CUI Inc. SWI25-18-N-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	North America	25 W	1.4 A	ITE (Commercial)	1.8 m	70.9 "	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	Level VI	Fixed Blade	NEMA 1-15P	-20 ░C	40 °C	Positive Center	18 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1
CUI Inc. SWI25-24-E-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	Europe	25 W	1.05 A	ITE (Commercial)	1.8 m	70.9 "	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	CoC Tier 2 Level VI	Fixed Blade	CEE 7/16	-20 ░C	40 °C	Positive Center	24 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1	EN FCC SIQ TUV
CUI Inc. SWI25-15-E-P5	48.4 mm	1.3 in	1.91 in	33 mm	2.8 in	71 mm	Wall Mount	Europe	25 W	1.67 A	ITE (Commercial)	1.8 m	70.9 "	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	CoC Tier 2 Level VI	Fixed Blade	CEE 7/16	-20 ░C	40 °C	Positive Center	15 V	75 mW	264 VAC	90 VAC	55011 Class B 60950-1 61000-3-2 61000-3-3 61000-6-1 62368-1	EN FCC SIQ TUV
